G 1
10 1098/1098S - M.Y. 2007 - edition 00
Wheels - Suspensions - Brakes
Before tightening the axle clamp bolts (8), lower the bike to the ground and press up and down on the handlebars to load the
suspension so the fork legs will become properly seated onto the wheel axle.
Lubricate the bolts (8).
Tighten the bolts (8) to the specified torque (Sect. C 3), in the sequence 1-2-1.
8
8
