Injection - ignition system
Checking the coils
The coils used on this model are known as “cigar” coils.
They are similar in appearance to a spark plug cap. They transform the low voltage from the ECU into high voltage for the spark
plugs.
To test the coils, proceed as follows:
Measure the resistance between the two pins (1-15).
The resistance should be 650 mΩ±50; if not, replace the coil.
Notes
To check the coils for faults, use the DDS tester and follow the instructions given under the heading “Guided diagnosis”,
Sect. D 5.
