section
N 6.1
1171098/1098S - M.Y. 2007 - edition 00
Engine
Remove the clutch lifter (3) and its O-ring (17) using a suitable drift and a plastic headed mallet.
Then remove the bearing (14) installed from inner side of the pressure plate (12) using a drift of suitable size.
Notes
Once disturbed, the bearing must be renewed.
Remove the clutch plates (8).
When removing the clutch plates, keep them together in pairs in the correct order and set them aside, tying them together, if
necessary.
12
3
12
8
