71098/1098S - M.Y. 2007 - edition 00
General summary
6 - Airbox - Throttle Body 14
Removal of the throttle body 15
Refitting the airbox and throttle body 23
7 - Air intake 29
Removal of the air filters 30
Refitting the air filters 31
8 - Exhaust system 32
Removal of the exhaust system 33
Refitting the exhaust system 37
Section M
Injection - ignition system 0
2 - Fuel injection-ignition system 3
3 - System components 4
Electronic Control Unit (ECU) 4
Removal of the battery support 6
Refitting the battery support 9
Electric injector 14
Air pressure sensor 15
Coolant temperature sensor 16
Air temperature sensor 17
Ignition coils 18
Throttle Position Sensor (TPS) 21
Rpm/timing sensor 22
Injection relay 23
CAN Line 24
Section N
Engine 0
1 - Removal–refitting of the engine assembly 5
Removal of the engine 6
Refitting the engine 9
2.1 - Lubrication system: oil pump 10
Removal of the oil pump 11
Disassembly of the oil pump 12
Reassembly of the oil pump 13
Refitting the oil pump 14
2.2 - Lubrication system: oil cooler 15
Removal of the lubrication system 16
Oil cooler inspection 18
Refitting the lubrication system 18
