Reinstall the filter cartridge in its seat in the filter housing and refit all removed parts and structures.
Important
If the motorcycle is used in very damp or dusty conditions, the air filter element must be changed more frequently.
Check the air filter (5) located in the horizontal cylinder timing belt cover (6): to remove the filter, remove the cover (Sect. N 4.2)
and remove the screws (7).
After inspection, refit the filter (5), tighten the screws (7) and replace the horizontal cylinder timing belt cover (6) (Sect. N 4.2).
7
5
6
