section
P 7
991098/1098S - M.Y. 2007 - edition 00
Electric system
Instrument panel diagnostics
Important
The instrument runs the system diagnostics correctly 60 seconds after the last Key-Off.
Any anomalous behaviours of the motorcycle are displayed.
If there are several errors, they are displayed in rolling mode every 3 seconds.
The table below shows the errors that can be displayed.
Warning
light
Error message Error
COIL 10.1 Horizontal cylinder coil error
COIL 10.2 Horizontal cylinder coil error
COIL 11.1 Vertical cylinder coil error
COIL 11.2 Vertical cylinder coil error
INJE 12.1 Horizontal cylinder injector error
INJE 12.2 Horizontal cylinder injector error
INJE 13.1 Vertical cylinder injector error
INJE 13.2 Vertical cylinder injector error
PUMP 16.0 Fuel pump relay error
FAN 18.1 Fan relay error
FAN 18.2 Fan relay error
STRT 19.1 Starter contactor error
STRT 19.2 Starter contactor error
STEP. 21.1 Stepper motor error
STEP. 21.2 Stepper motor error
STEP. 21.3 Stepper motor error
LAMB. 22.1 Lambda heater error
LAMB. 22.2 Lambda heater error
EXVL 23.1 Exhaust valve motor error
EXVL 23.2 Exhaust valve motor error
EXVL 23.3 Exhaust valve motor error
EXVL 23.4 Exhaust valve motor error
EXVL 23.5 Exhaust valve motor error
TPS 1.1 Throttle position sensor error
TPS 1.2 Throttle position sensor error
PRESS 2.1 Pressure sensor error
PRESS 2.2 Pressure sensor error
T.WAT 3.1 Engine coolant temperature sensor error
T.WAT 3.2 Engine coolant temperature sensor error
