112 1098/1098S - M.Y. 2007 - edition 00
Electric system
10 - USB Data Acquisition (DAQ) (for 1098S only)
A USB DAQ (1) is supplied in kit form. To use it, position it under the seat with the cap (2) fitted and the connector (3) from
the main wiring loom connected. Refer to the instrument panel functions (Sect. P 7, Display settings and functions).
3
1
2
3
