D 4
231098/1098S - M.Y. 2007 - edition 00
Use and maintenance
Connect a commercially available brake bleeder to the bleed valve (3) or (5).
Loosen the bleed valve (3) or (5) and pump with the bleeder until no more fluid is draining off.
Notes
Follow the manufacturer's instructions when using a commercial brake bleeding tool.
If you do not have a bleeder available, attach a length of transparent plastic tubing to the bleed valve (3) or (5) and insert the other
end of the tubing in a container of old brake fluid placed on the floor.
Unscrew the bleed valve by a 1/4 turn.
Operate the brake lever (or pedal) until all the fluid has drained out.
Repeat this operation for each brake caliper.
3
5
