section
D 4
311098/1098S - M.Y. 2007 - edition 00
Use and maintenance
Open the bleed valve by a 1/4 turn and operate the clutch lever several times until the fluid starts to emerge from the bleed
valve (2).
Pull the lever fully in and then slacken off the bleed valve by at least a 1/4 turn.
Wait for a few seconds, then release the lever gradually while simultaneously closing the bleed valve (2).
Important
Do not release the clutch lever until the bleed valve has been fully tightened.
Repeat the bleeding operation until air bubbles no longer come out of the plastic tube.
Tighten the bleed valve (3) to the specified torque (Sect. C 2). Replace the dust cap.
Top up the fluid level to approximately 3 mm above the MIN mark on the reservoir.
Replace the cap (1) with the membrane.
MAX
MIN
1
