D 4
34 1098/1098S - M.Y. 2007 - edition 00
Use and maintenance
If the clamp bolts (1) are removed, lubricate the threads and the underside of the head of each bolt, then tighten the bolts (1) to
the specified torque in the sequence 1-2-1.
Warning
For the safety of the rider, it is essential that the eccentric hub clamp bolts are correctly tightened (Sect. C 3).
B
1
