C
HAPTER
15
| Multicast Filtering
Filtering and Throttling IGMP Groups
– 407 –
When the access mode is set to deny, IGMP join reports are only
processed when the multicast group is not in the controlled range.
Add Multicast Group Range
◆ Profile ID – Selects an IGMP profile to configure.
◆ Start Multicast IP Address – Specifies the starting address of a
range of multicast groups.
◆ End Multicast IP Address – Specifies the ending address of a range
of multicast groups.
WEB INTERFACE
To create an IGMP filter profile and set its access mode:
1. Click Multicast, IGMP Snooping, Filtering.
2. Select Add from the Action list.
3. Enter the number for a profile, and set its access mode.
4. Click Apply.
Figure 238: Creating an IGMP Filtering Profile
To show the IGMP filter profiles:
1. Click Multicast, IGMP Snooping, Filtering.
2. Select Show from the Action list.
Figure 239: Showing the IGMP Filtering Profiles Created
