C
HAPTER
15
| Multicast Filtering
Filtering and Throttling IGMP Groups
– 408 –
To add a range of multicast groups to an IGMP filter profile:
1. Click Multicast, IGMP Snooping, Filtering.
2. Select Add Multicast Group Range from the Action list.
3. Select the profile to configure, and add a multicast group address or
range of addresses.
4. Click Apply.
Figure 240: Adding Multicast Groups to an IGMP Filtering Profile
To show the multicast groups configured for an IGMP filter profile:
1. Click Multicast, IGMP Snooping, Filtering.
2. Select Show Multicast Group Range from the Action list.
3. Select the profile for which to display this information.
Figure 241: Showing the Groups Assigned to an IGMP Filtering Profile
