C
HAPTER
3
| Using the Web Interface
Navigating the Web Browser Interface
– 98 –
OSPF Open Shortest Path First (Version 2) 502
Network Area 504
Add Defines OSPF area address, area ID, and process ID 504
Show Shows configured areas 504
Show Process Show configured processes 504
System 507
Configure Configures the Router ID, global settings, and default information 507
Show Shows LSA statistics, administrative status, ABR/ASBR, area
count, and version number
510
Area 512
Configure Area 512
Add Area Adds NSSA or stub 512
Show Area Shows configured NSSA or stub 512
Configure NSSA Area Configures settings for importing routes into or exporting routes
out of not-so-stubby areas
513
Configure Stub Area Configures default cost, and settings for importing routes into a
stub
516
Show Information Shows statistics for each area, including SPF startups, ABR/ASBR
count, LSA count, and LSA checksum
518
Area Range 519
Add Configures route summaries to advertise at an area boundary 519
Show Shows route summaries advertised at an area boundary 519
Modify Modifies route summaries advertised at an area boundary 519
Redistribute 521
Add Redistributes routes from one routing domain to another 521
Show Shows route types redistributed to another domain 521
Modify Modifies configuration settings for redistributed routes 521
Summary Address 523
Add Aggregates routes learned from other protocols for advertising
into other autonomous systems
523
Show Shows configured summary addresses 523
Interface 525
Configure by VLAN Configures OSPF protocol settings and authentication for specified
VLAN
525
Configure by Address Configures OSPF protocol settings and authentication for specified
interface address
525
Show MD5 Key Shows MD5 key ID used for each areaa 525
Virtual Link 531
Add Configures a virtual link through a transit area to the backbone 531
Table 4: Switch Main Menu (Continued)
Menu Description Page
