6 – 79
Chapter 6 General
Tray Sensor
1) Turn on the power and enter the FAX Scanner Diag.
2) Set a paper in the ADF Tray.
3) Execute "Tray Sensor".
4) Check the sensor "Status ON".
5) Press "STOP" key to return one step higher menu.
6) Remove a paper in the ADF Tray.
7) Execute "Tray Sensor".
8) Check the sensor "Status OFF".
9) Press "STOP" key to stop the test
Sensor name Confirmation Procedures
Mnt02052GA
Operator Panel
Normal
To Next Page
