7½ Digit Graphical Sampling Multimeter Reference Manual Appendix 0:
DMM7510-901-01 Rev. B / May 2015 7
4. Select your communication interface from the Select Instrument dialog box. See the Connecting
an instrument in TSB (on page 7-34) for details on opening communications.
5. On the Instrument Console toolbar, click the View Menu icon. Select Instrument, then select
Flash.
6. From the Select a Firmware Image File dialog box, use the browser to select the file name of the
new firmware or enter the path and file name.
7. If you are upgrading the firmware, replace the existing firmware with a newer version of firmware.
8. If you are downgrading the firmware, replace the existing firmware with an older version of
firmware or repair the same version.
9. Click OK. A Progress Information bar is displayed on the instrument during the update. In
addition, the LEDs in the upper right of the front panel blink while the upgrade is in process.
10. Wait until the instrument indicates that the firmware upgrade is complete (TSB may indicate that
the upgrade is complete before it is finalized on the instrument).
11. Reboot the instrument.
