8: TSP command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
8-194 DMM7510-901-01 Rev. B / May 2015
dmm.measure.threshold.autorange
This attribute determines if the threshold range is set manually or automatically.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW) Yes
Restore configuration
Instrument reset
Power cycle
Measure configuration list
Configuration script
Measure configuration list
dmm.ON
Usage
state = dmm.measure.threshold.autorange
dmm.measure.threshold.autorange = state
• Disable: dmm.OFF
• Enable:
Functions
dmm.FUNC_DIGITIZE_CURRENT
dmm.FUNC_DIGITIZE_VOLTAGE
Details
This command determines how the range is selected.
When this command is set to off, you must set the range. If you do not set the range, the instrument
remains at the range that was selected by autorange.
When this command is set to on, the instrument uses the signal to determine the most sensitive
range on which to perform the measurement. The instrument sets the range when a measurement is
requested. To set the range, the instrument makes a measurement to determine the range before
making the final measurement, which can result in slower reading times. Turn autorange off and set a
specific range to increase measure time.
If a range is manually selected through the front panel or a remote command, this command is
automatically set to off.
Example
dmm.measure.func = dmm.FUNC_ACV_PERIOD
dmm.measure.threshold.autorange = dmm.ON
Set the measure function to period.
Set the threshold autorange on.
Also see
dmm.measure.threshold.level (on page 8-195)
dmm.measure.threshold.range (on page 8-196)
