7½ Digit Graphical Sampling Multimeter Reference Manual Section 8:
DMM7510-901-01 Rev. B / May 2015 8-155
dmm.measure.func
This attribute selects the active measure function.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW) Yes
Restore configuration
Instrument reset
Power cycle
Measure configuration list
Configuration script
Measure configuration list
dmm.FUNC_DC_VOLTAGE
Usage
mFunction = dmm.measure.func
dmm.measure.func = mFunction
The type of measurement; see Functions for options
Functions
dmm.FUNC_DIGITIZE_CURRENT
dmm.FUNC_DIGITIZE_VOLTAGE
Details
Set this command to the type of measurement you want to make. Reading this command returns the
measure function that is presently active.
When you select a function, settings for other commands that are related to the function become
active. For example, assume that:
• You selected the current function and set the math function to reciprocal.
• You changed to the voltage function and set the math function to percent.
If you return to the current function, the math function returns to reciprocal. If you then switch from the
current function to the voltage function, the math function returns to percent. All attributes that begin
with dmm.measure. are saved with the active measure function unless otherwise indicated in the
command description.
If a digitize measurement function is active, calling this command returns dmm.FUNC_NONE. The no
function setting is automatically made if you select a function with dmm.digitize.func or through
the options from the front-panel Digitize Functions tab.
