8: TSP command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
8-286 DMM7510-901-01 Rev. B / May 2015
trigger.model.load() — Config List
This function loads a predefined trigger model configuration that uses a measure configuration list.
Type TSP-Link accessible
Affected by Where saved Default value
Usage
trigger.model.load("ConfigList", measureConfigList)
trigger.model.load("ConfigList", measureConfigList, delay)
trigger.model.load("ConfigList", measureConfigList, delay, bufferName)
trigger.model.load("ConfigList", measureConfigList, delay, bufferName,
readingBlock)
A string that contains the name of the measurement configuration list to
use
The delay time before each measurement (167 ns to 10 ks); default is 0 for
no delay
The name of the reading buffer, which may be a default buffer
(defbuffer1 or defbuffer2) or a user-defined buffer; defaults to
.
Define a measure or digitize block for the trigger model; options are:
• trigger.READING_ACTIVE: Add a measure or digitize block to the
trigger model based on the active function; if no option defined,
trigger.READING_ACTIVE is used
• trigger.READING_MEASURE: Adds a measure block to the trigger
model
• trigger.READING_DIGITIZE: Adds a digitize block to the trigger
Details
This trigger model template incorporates a configuration list. You must set up the configuration lists
before loading the trigger model.
You can also set a delay and change the reading buffer.
The out line of the EXT TRIG IN/OUT rear-panel terminal is asserted at the end of each
measurement.
After selecting a trigger model template, you can view the trigger model blocks in a graphical format
by pressing the front-panel MENU key and under Trigger, selecting Configure. You can also add or
delete blocks and change trigger model settings from this screen. You can use the
trigger.model.getblocklist() command to view the trigger model blocks in a list format.
