Keithley DMM7510 Reference Manual

Section
6: SCPI command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
Reference Manual
6-214 DMM7510-901-01 Rev. B / May 2015
Example
:TRIG:LAN2:IN:EDGE FALL
Set the LAN trigger mode for event 2 to falling.
Also see
Digital I/O (on page 3-47)
TSP-Link System Expansion Interface (on page 3-104)
:TRIGger:LAN<n>:IN:OVERrun?
This command indicates the overrun status of the LAN event detector.
Type Affected by Where saved Default value
Query only
TRIGger:LAN<n>:IN:CLEar
Not applicable
Not applicable
Usage
:TRIGger:LAN<n>:IN:OVERrun?
<n>
The LAN event number (1 to 8)
Details
This command indicates whether an event has been ignored because the event detector was already
in the detected state when the event occurred.
This is an indication of the state of the event detector built into the synchronization line itself. It does
not indicate if an overrun occurred in any other part of the trigger model, or in any other construct that
is monitoring the event.
It also is not an indication of an output trigger overrun.
The trigger overrun state for the specified LAN packet is returned as 1 (true) or 0 (false).
Example
TRIG:LAN5:IN:OVER?
Checks the overrun status of a trigger on LAN5
and outputs the value, such as:
0
Also see
:TRIGger:LAN<n>:IN:CLEar (on page 6-213)

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
