6: SCPI command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
Reference Manual
6-188 DMM7510-901-01 Rev. B / May 2015
• Inside: The measurement is inside the values set by limits A and B; limit A must be the low value
and Limit B must be the high value
• Outside: The measurement is outside the values set by limits A and B; limit A must be the low
value and Limit B must be the high value
The measurement block must be a measure or digitize building block that occurs in the trigger model
before the branch-on-constant-limits block. The last measurement from a measure or digitize building
block is used.
If the limit A is more than the limit B, the values are automatically swapped so that the lesser value is
used as the lower limit.
Example
TRIGger:BLOCk:BRANch:LIMit:CONStant 5, OUTside, 0.15, 0.65, 8
Configure trigger block 5 to check for measurements in the last measure or digitize block. If the
measurements are outside of the 0.15 and 0.65 limits, branch to block 8.
Also see
Constant Limit block (on page 3-85)
:TRIGger:BLOCk:BRANch:LIMit:DYNamic
This command defines a trigger model block that goes to a specified block in the trigger model if a measurement
meets user-defined criteria.
Type Affected by Where saved Default value
Command only
Recall settings
Instrument reset
Power cycle
Save settings Not applicable
Usage
:TRIGger:BLOCk:BRANch:LIMit:DYNamic <blockNumber>, <limitType>, <limitNumber>,
<branchToBlock>
:TRIGger:BLOCk:BRANch:LIMit:DYNamic <blockNumber>, <limitType>, <limitNumber>,
<branchToBlock>, <measureBlock>
<blockNumber>
The sequence of the block in the trigger model
<limitType>
The type of limit (ABOVe, BELow, INside, or OUTside)
<limitNumber>
The limit number (1 or 2)
<branchToBlock>
The block number of the trigger model block to execute when the limits
are met
<measureBlock>
The block number of the measure or digitize block that makes the
measurements to be compared; if this is 0 or undefined, the trigger model
uses the previous measure or digitize block
