8: TSP command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
Reference Manual
8-348 DMM7510-901-01 Rev. B / May 2015
tsplink.line[N].mode
This attribute defines the trigger operation of a TSP-Link line.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW) Yes
Restore configuration
Instrument reset
Power cycle
TSP-Link line N reset
Configuration script tsplink.MODE_DIGITAL_OPEN_DRAIN
Usage
mode = tsplink.line[N].mode
tsplink.line[N].mode = mode
mode
The trigger mode; see Details
N
The trigger line (1 to 3)
Details
This command defines whether or not the line is used as a digital or trigger control line and if it is an
input or output.
The line mode can be set to the following options:
• TSP-Link digital open drain line: tsplink.MODE_DIGITAL_OPEN_DRAIN
• TSP-Link trigger open drain line: tsplink.MODE_TRIGGER_OPEN_DRAIN
• TSP-Link trigger synchronous master: tsplink.MODE_SYNCHRONOUS_MASTER
• TSP-Link trigger synchronous acceptor: tsplink.MODE_SYNCHRONOUS_ACCEPTOR
Example
tsplink.line[3].mode = tsplink.MODE_TRIGGER_OPEN_DRAIN
Sets the trigger mode for
synchronization line 3 as a
trigger open drain line.
Also see
trigger.tsplinkin[N].edge (on page 8-339)
trigger.tsplinkout[N].logic (on page 8-342)
