Keithley DMM7510 Reference Manual

Section
8: TSP command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
Reference Manual
8-320 DMM7510-901-01 Rev. B / May 2015
trigger.model.setblock() — trigger.BLOCK_LOG_EVENT
This function allows you to log an event in the event log when the trigger model is running.
Type TSP-Link accessible Affected by Where saved Default value
Function
Yes
Restore configuration
Instrument reset
Power cycle
Configuration script
Not applicable
Usage
trigger.model.setblock(blockNumber, trigger.BLOCK_LOG_EVENT, eventNumber, message)
blockNumber
The sequence of the block in the trigger model
eventNumber
The event number:
• trigger.LOG_INFON
• trigger.LOG_WARNN
• trigger.LOG_ERRORN
Where N is 1 to 4; you can define up to four of each type
You can also set trigger.LOG_WARN_ABORT, which aborts the trigger model
immediately and posts a warning event log message
message
A string up to 31 characters
Details
This block allows you to log an event in the event log when trigger model execution reaches this
block. You can also force the trigger model to abort with this block. When the trigger model executes
the block, the defined event is logged. If the abort option is selected, the trigger model is also aborted
immediately.
You can define the type of event (information, warning, abort model, or error). All events generated by
this block are logged in the event log. Warning and error events are also displayed in a popup on the
front-panel display.
Note that using this block too often in a trigger model could overflow the event log. It may also take
away from the time needed to process more critical trigger model blocks.
Example
trigger.model.setblock(9, trigger.BLOCK_LOG_EVENT, trigger.LOG_INFO2, "Trigger
model complete.")
Set trigger model block 9 to log an event when the trigger model completes. In the event log, the message is:
TM #1 block #9 logged: Trigger model complete.
Also see
None

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
