Keithley DMM7510 Reference Manual

Model DMM7510
7½ Digit Graphical Sampling Multimeter Reference Manual Section 8:
TSP command reference
DMM7510-901-01 Rev. B / May 2015 8-313
trigger.model.setblock() — trigger.BLOCK_CONFIG_NEXT
This function recalls the settings at the next index of a configuration list.
Type TSP-Link accessible Affected by Where saved Default value
Function
Yes
Restore configuration
Instrument reset
Power cycle
Configuration script
Not applicable
Usage
trigger.model.setblock(blockNumber, trigger.BLOCK_CONFIG_NEXT, configurationList)
blockNumber
The sequence of the block in the trigger model
configurationList
A string that defines the configuration list to recall
Details
When trigger model execution reaches a configuration recall next block, the settings at the next index
in the specified configuration list are restored.
The first time the trigger model encounters this block for a specific configuration list, the first index is
recalled. Each subsequent time this block is encountered, the settings at the next index in the
configuration list are recalled and take effect before the next step executes. When the last index in
the list is reached, it returns to the first index.
The configuration list must be defined before you can use this block.
Example
trigger.model.setblock(5, trigger.BLOCK_CONFIG_NEXT, "measTrigList")
Configure trigger block 5 to load the next index in the configuration list named
measTrigList
.
Also see
Configuration lists (on page 3-37)
trigger.model.setblock() — trigger.BLOCK_CONFIG_PREV
This function defines a trigger model block that recalls the settings stored at the previous index in a configuration
list.
Type TSP-Link accessible Affected by Where saved Default value
Function
Yes
Restore configuration
Instrument reset
Power cycle
Configuration script
Not applicable
Usage
trigger.model.setblock(blockNumber, trigger.BLOCK_CONFIG_PREV, configurationList)
blockNumber
The sequence of the block in the trigger model
configurationList
A string that defines the measure configuration list to recall

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
