8: TSP command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
8-312 DMM7510-901-01 Rev. B / May 2015
Details
The branch-once-excluded block is ignored the first time the trigger model encounters it. After the first
encounter, the trigger model goes to the specified branching block.
The branch-once-excluded block is reset when the trigger model starts or is placed in idle.
Example
trigger.model.setblock(2, trigger.BLOCK_BRANCH_ONCE_EXCLUDED, 4)
When the trigger model reaches block 2 the first time, the trigger model goes to block 3. If the trigger model
reaches this block again, the trigger model goes to block 4.
Also see
Once excluded block (on page 3-87)
trigger.model.setblock() — trigger.BLOCK_BUFFER_CLEAR
This function defines a trigger model block that clears the reading buffer.
Type TSP-Link accessible Affected by Where saved Default value
Instrument reset
Usage
trigger.model.setblock(blockNumber, trigger.BLOCK_BUFFER_CLEAR)
trigger.model.setblock(blockNumber, trigger.BLOCK_BUFFER_CLEAR, bufferName)
The sequence of the block in the trigger model
The name of the buffer, which must be an existing buffer; if no
buffer is defined,
is used
Details
When trigger model execution reaches the buffer clear trigger block, the instrument empties the
specified reading buffer. The specified buffer can be the default buffer or a buffer that you defined.
If you are clearing a user-defined reading buffer, you must create the buffer before you define this
block.
Example
trigger.model.setblock(3, trigger.BLOCK_BUFFER_CLEAR, capTest2)
Assign trigger block 3 to buffer clear; when the trigger model reaches block 3, it clears the reading buffer
named
.
Also see
buffer.make() (on page 8-18)
Buffer clear block (on page 3-80)
