Keithley DMM7510 Reference Manual

Model DMM7510
7½ Digit Graphical Sampling Multimeter Reference Manual Appendix 0:
Status model
DMM7510-901-01 Rev. B / May 2015 13
Reading the registers
You can read any register in the status model. The response is a decimal value that indicates which
bits in the register are set. See Understanding bit settings (on page 14
) for information on how to
convert the decimal value to bits.
Using SCPI commands:
If you are using SCPI, you use the query commands in the STATus subsystem and common
commands to read registers.
Using TSP commands:
If you are using TSP, you print the TSP command to read the register. You can use either print(),
which returns the decimal value, or print(tostring()), which returns the string equivalent of the
decimal value.
You can also send the common commands to read the register.
For example, you can send any one of the following commands to read the Status Enable Register of
the Standard Event Register:
print(status.standard.enable)
*ese?
print(tostring(status.standard.enable))

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
