Keithley DMM7510 Reference Manual

Section
8: TSP command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
Reference Manual
8-208 DMM7510-901-01 Rev. B / May 2015
Details
This command saves all event log entries to a USB flash drive.
If you do not define an event type, the instrument saves all event log entries.
The extension .csv is automatically added to the file name.
Example
eventlog.save("/usb1/WarningsApril", eventlog.SEV_WARN)
Save warning messages to a
.csv file on a USB flash drive
Also see
eventlog.next() (on page 8-205)
exit()
This function stops a script that is presently running.
Type TSP-Link accessible
Affected by Where saved Default value
Function No
Usage
exit()
Details
Terminates script execution when called from a script that is being executed.
This command does not wait for overlapped commands to complete before terminating script
execution. If overlapped commands are required to finish, use the waitcomplete() function before
calling exit().
Also see
waitcomplete() (on page 8-368)
fan.level
This attribute sets the speed of the instrument fan.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW)
Yes
Never
Not applicable
fan.LEVEL_NORMAL
Usage
fanLevel = fan.level
fan.level = fanLevel
fanLevel
The fan level:
Normal fan operation: fan.LEVEL_NORMAL
Quiet fan operation:
fan.LEVEL_QUIET

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
