Keithley DMM7510 Reference Manual

Model DMM7510
7½ Digit Graphical Sampling Multimeter Reference Manual Section 2: General op
eration
DMM7510-901-01 Rev. B / May 2015 2-139
Resistance autodelay and autorange times
The following tables provide times for autodelay and autorange for the Model DMM7510 DMM
resistance functions.
For continuity, the range is 1 kΩ with an autodelay of 3 ms and auto range of 25 ms.
Function Range and delays
2-wire ohm
and 4-wire
ohm
Range
1 - 100 Ω 1 kΩ 10 kΩ 100 kΩ 1 MΩ 10 MΩ 100 MΩ 1 GΩ
Autodelay
3 ms
3 ms
13 ms
25 ms
100 ms
250 ms
375 ms
375 ms
Autorange
2.5 ms
25 ms
125 ms
250 ms
1 s
2.5 s
3.75 s
3.75 s
Function Range and delays
Dry circuit
ohms
Range
1 - 10 Ω 100 - 2 kΩ
Autodelay
3 ms 13 ms
Autorange
2.5 ms
125 ms
Frequency and period autodelay and autorange times
The following table provides times for autodelay and autorange for the Model DMM7510 DMM
frequency and period functions.
Function Ranges and delays
Frequency and
periods
Range
100 mV
1 V
10 V
100 V
700 V
Autodelay
100 ms
Autorange
1 s
Temperature autodelay and autorange times
The following table provides times for autodelay and autorange for the Model DMM7510 DMM
thermistor and RTD temperature functions.
When thermocouple is selected, the range is 100 mV, with an autodelay of 1 ms and an autorange of
10 ms.
Function Range and delays
Thermistor
Range
1
Ω
– 100
Ω
1 k
Ω
10 k
Ω
100 k
Ω
Autodelay
3 ms
3 ms
13 ms
25 ms
Autorange
25 ms
25 ms
125 ms
250 ms
3-Wire and
4-Wire RTD
Range
100
Ω
1 k
Ω
10 k
Ω
100 k
Ω
Autodelay
3 ms
3 ms
13 ms
25 ms
Autorange
25 ms
25 ms
125 ms
250 ms
