Keithley DMM7510

Section
8: TSP command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
Reference Manual
8-344 DMM7510-901-01 Rev. B / May 2015
trigger.tsplinkout[N].stimulus
This attribute specifies the event that causes the synchronization line to assert a trigger.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW) Yes
Restore configuration
Instrument reset
Power cycle
TSP-Link line N reset
Configuration script trigger.EVENT_NONE
Usage
event = trigger.tsplinkout[N].stimulus
trigger.tsplinkout[N].stimulus = event
event
The event identifier for the triggering event (see Details)
N
The trigger line (1 to 3)
Details
To disable automatic trigger assertion on the synchronization line, set this attribute to
trigger.EVENT_NONE.
Do not use this attribute when triggering under script control. Use
trigger.tsplinkout[N].assert() instead.
The event parameters that you can use are described in the table below.
Trigger events
Event description Event constant
No trigger event
trigger.EVENT_NONE
Front-panel TRIGGER key press
trigger.EVENT_DISPLAY
Notify trigger block N (1 to 8) generates a trigger event when the
trigger model executes it
trigger.EVENT_NOTIFYN
A command interface trigger (bus trigger):
• Any remote interface: *TRG
• GPIB only: GET bus command
•
VXI-11: VXI-11 command device_trigger
trigger.EVENT_COMMAND
Line edge (either rising, falling, or either based on the configuration of
the line) detected on digital input line
N
(1 to 6)
trigger.EVENT_DIGION
Line edge detected on TSP-Link synchronization line
N
(1 to 3)
trigger.EVENT_TSPLINKN
Appropriate LXI trigger packet is received on LAN trigger object N (1
to 8)
trigger.EVENT_LANN
