Keithley DMM7510 Reference Manual

Section
3: Functions and features Model DMM7510 7½ Digit Graphical Sampling Multimeter
Reference Manual
3-10 DMM7510-901-01 Rev. B / May 2015
Setting reciprocal math operations
From the front panel:
1. Press the FUNCTION key and select the measure function.
2. Press the MENU key.
3. Under Measure, select Calculations.
4. For Math, select On.
5. Select Config.
6. For Math Format, select Reciprocal
7. Select OK.
8. Press the HOME key to view the measure with the reciprocal math format applied.
Over a remote interface:
• SCPI commands: Refer to :CALCulate[1]:<function>:MATH:FORMat (on page 6-31).
• TSP commands: Refer to dmm.measure.math.format (on page 8-168).
Switching math on the SETTINGS swipe screen
Once you set the math operations settings for a measure function, you can turn the math function on
or off on the SETTINGS swipe screen.
From the front panel:
1. Select HOME.
2. Go the SETTINGS swipe screen.
3. Select the button next to Math to enable or disable the math operation.
4. To change other math settings, touch the calculations settings icon on the right side of the
settings swipe screen to open the CALCULATION SETTINS screen.

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
