Keithley DMM7510 Reference Manual

Section
6: SCPI command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
Reference Manual
6-192 DMM7510-901-01 Rev. B / May 2015
Details
When trigger model execution reaches a configuration recall next block, the settings at the next index
in the specified configuration list are restored.
The first time the trigger model encounters this block for a specific configuration list, the first index is
recalled. Each subsequent time this block is encountered, the settings at the next index in the
configuration list are recalled and take effect before the next step executes. When the last index in
the list is reached, it returns to the first index.
The configuration list must be defined before you can use this block.
Example
TRIG:BLOC:CONF:NEXT 12, "SETTINGS_LIST"
Set trigger block 12 to restore the settings
from the next index that is stored in the
configuration list
SETTINGS_LIST
.
Also see
Configuration lists (on page 3-37)
:TRIGger:BLOCk:CONFig:PREVious
This command defines a trigger model block that recalls the settings stored at the previous index in a
configuration list.
Type Affected by Where saved Default value
Command only
Recall settings
Instrument reset
Power cycle
Save settings Not applicable
Usage
:TRIGger:BLOCk:CONFig:PREVious <blockNumber>, "<configurationList>"
<blockNumber>
The sequence of the block in the trigger model
<configurationList>
The configuration list from which to recall settings
Details
The Config List Prev building block defines a trigger model block that recalls the settings stored at the
previous index in a configuration list.
The configuration list previous index trigger block type recalls the previous index in a configuration
list. It configures the settings of the instrument based on the settings at that index. The trigger model
executes the settings at that index before the next block is executed.
The first time the trigger model encounters this block, the last index in the configuration list is recalled.
Each subsequent time trigger model execution reaches a configuration list previous block for this
configuration list, it goes backward one index. When the first index in the list is reached, it goes to the
last index in the configuration list.
You must create the configuration list before you can define it in this building block.

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
