Model DMM7510

7½ Digit Graphical Sampling Multimeter Reference Manual Section 6:

SCPI command reference

DMM7510-901-01 Rev. B / May 2015 6-181

Example

:DIG:LINE3:MODE TRIG, IN

:DIG:LINE5:MODE TRIG, IN

:TRIG:BLEN1:MODE OR

:TRIG:BLEN1:STIM1 DIG3

:TRIG:BLEN1:STIM2 DIG5

Set digital I/O lines 3 and 5 as trigger in

lines. Generate a trigger blender 1 event

when a digital I/O trigger happens on line 3

or 5.

Also see

:TRIGger:BLENder<n>:MODE (on page 6-178)

:TRIGger:BLOCk:BRANch:ALWays

This command defines a trigger model block that always goes to a specific block.

Type Affected by Where saved Default value

Command only

Recall settings

Instrument reset

Power cycle

Save settings

Not applicable

Usage

:TRIGger:BLOCk:BRANch:ALWays <blockNumber>, <branchToBlock>

The sequence of the block in the trigger model

The block number of the trigger model block to execute when the trigger model

reaches this block

Details

When the trigger model reaches a branch-always building block, it goes to the building block set by

<branchToBlock>.

Example

TRIG:BLOC:BRAN:ALW 9, 20

When the trigger model reaches block 9, it

will always branch to block 20.

Also see

None
