2: General operation Model DMM7510 7½ Digit Graphical Sampling Multimeter
2-56 DMM7510-901-01 Rev. B / May 2015
The number of displayed digits does not affect accuracy or speed. It also does not affect the format of
readings that are returned from a remote command.
From the front panel:
1. Press MENU.
2. Under Measure, select Settings.
3. Next to Display Digits, select the number of digits to display.
This setting takes effect the next time you make a measurement.
From a remote interface:
• SCPI commands: Refer to :DISPlay:<function>:DIGits (on page 6-43).
• TSP commands: For measure functions, refer to dmm.measure.displaydigits (on page 8-148). For
digitize functions, refer to dmm.digitize.displaydigits (on page 8-89).
Setting the display format
You can set the format of units that are displayed for measurement readings on the front panel. The
formats are:
• Prefix: Add a prefix to the units symbol, such as k, m, or µ
• Exponent: Replace the units symbol with exponents
See the following figures for examples of each display format.
Figure 27: Model DMM7510 prefix display format
