Keithley DMM7510 Reference Manual

Section
6: SCPI command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
Reference Manual
6-206 DMM7510-901-01 Rev. B / May 2015
Example
TRIG:DIG1:IN:OVER?
Returns 0 if no overruns have occurred or 1
if one or more overrun have occurred for I/O
line 1.
Also see
Digital I/O port configuration (on page 3-49)
:DIGital:LINE<n>:MODE (on page 6-38)
:TRIGger:DIGital<n>:OUT:LOGic
This command sets the output logic of the trigger event generator to positive or negative for the specified line.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Save settings
NEG
Usage
:TRIGger:DIGital<n>:OUT:LOGic <logicType>
:TRIGger:DIGital<n>:OUT:LOGic?
<n>
Digital I/O trigger line (1 to 6)
<logicType>
The output logic of the trigger generator:
• Assert a TTL-high pulse for output: POSitive
• Assert a TTL-low pulse for output:
NEGative
Details
This command sets the trigger event generator to assert a TTL pulse for output logic. Positive is a
high pulse; negative is a low pulse.
Example
:DIG:LINE4:MODE TRIG, OUT
:TRIG:DIG4:OUT:LOG NEG
Sets line 4 mode to be a trigger output and
sets the output logic of the trigger event
generator to negative (asserts a low pulse).
Also see
:DIGital:LINE<n>:MODE (on page 6-38)
Digital I/O port configuration (on page 3-49)

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
