Keithley DMM7510 Reference Manual

Section
3: Functions and features Model DMM7510 7½ Digit Graphical Sampling Multimeter
Reference Manual
3-116 DMM7510-901-01 Rev. B / May 2015
Model DMM7510 TSP-Link command Replaces this command in other TSP-Link products
trigger.tsplinkin[N].clear()
tsplink.trigger[N].clear()
trigger.tsplinkin[N].edge
trigger.tsplinkout[N].logic
tsplink.line[
N
].mode
tsplink.trigger[N].mode
trigger.tsplinkin[N].overrun
tsplink.trigger[N].overrun
trigger.tsplinkin[N].wait()
tsplink.trigger[N].wait()
trigger.tsplinkout[N].assert()
tsplink.trigger[N].assert()
trigger.tsplinkout[N].pulsewidth
tsplink.trigger[N].pulsewidth
trigger.tsplinkout[N].release()
tsplink.trigger[N].release()
trigger.tsplinkout[N].stimulus
tsplink.trigger[N].stimulus
tsplink.initialize()
tsplink.reset()
tsplink.line[N].reset()
tsplink.trigger[N].reset()
tsplink.line[N].state
tsplink.readbit()
tsplink.writebit()
Not applicable
tsplink.writeprotect
TSP-Net
TSP-Net provides a simple socket-like programming interface to Test Script Processor (TSP) enabled
instruments. Using the TSP-Net library, the Model DMM7510 can control ethernet-enabled devices
directly through its LAN port. This enables the Model DMM7510 to communicate directly with a device
that is that is not TSP-enabled without the use of a controlling computer.
Using TSP-Net library methods, you can transfer string data to and from a remote instrument, transfer
and format data into Lua variables, and clear input buffers. The TSP-Net library is only accessible
using commands from a remote command interface when you are using the TSP command
language.
While you can use TSP-Net commands to communicate with any ethernet-enabled instrument,
specific TSP-Net commands exist for TSP-enabled instruments to allow for support of features unique
to the TSP scripting engine. These features include script downloads, reading buffer access, wait
completion, and handling of TSP scripting engine prompts.
Using TSP-Net commands with TSP-enabled instruments, a Model DMM7510 can download a script
to another TSP-enabled instrument and have both instruments run scripts independently. The Model
DMM7510 can read the data from the remote instrument and either manipulate the data or send the
data to a different remote instrument on the LAN.
You can use TSP-Net to connect to a computer; you can use a script on the instrument to transfer
data directly to your computer hard drive.
With TSP-Net, you can simultaneously connect to a maximum of 32 devices using standard TCP/IP
networking techniques through the LAN port of the Model DMM7510.

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
