Keithley DMM7510 Reference Manual

Section
8: TSP command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
Reference Manual
8-256 DMM7510-901-01 Rev. B / May 2015
trigger.blender[N].reset()
This function resets some of the trigger blender settings to their factory defaults.
Type TSP-Link accessible
Affected by Where saved Default value
Function
Yes
Usage
trigger.blender[N].reset()
N
The trigger event blender (1 or 2)
Details
The trigger.blender[N].reset() function resets the following attributes to their factory
defaults:
• trigger.blender[N].orenable
• trigger.blender[N].stimulus[M]
It also clears trigger.blender[N].overrun.
Example
trigger.blender[1].reset()
Resets the trigger blender 1
settings to factory defaults.
Also see
trigger.blender[N].orenable (on page 8-254)
trigger.blender[N].overrun (on page 8-255)
trigger.blender[N].stimulus[M] (on page 8-256)
trigger.blender[N].stimulus[M]
This attribute specifies the events that trigger the blender.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW)
Yes
Restore configuration
Instrument reset
Power cycle
Trigger blender N reset
Configuration script
trigger.EVENT_NONE
Usage
event = trigger.blender[N].stimulus[M]
trigger.blender[N].stimulus[M] = event
event
The event that triggers the blender action; see Details
N
An integer that represents the trigger event blender (1 or 2)
M
An integer representing the stimulus index (1 to 4)
Details
There are four stimulus inputs that can each select a different event.
Use zero to disable the blender input.

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
