7½ Digit Graphical Sampling Multimeter Reference Manual Section 6: SCPI co
DMM7510-901-01 Rev. B / May 2015 6-199
Details
This block allows you to log an event in the event log when trigger model execution reaches this
block. You can also force the trigger model to abort with this block. When the trigger model executes
the block, the defined event is logged. If the abort option is selected, the trigger model is also aborted
immediately.
You can define the type of event (information, warning, abort model, or error). All events generated by
this block are logged in the event log. Warning and error events are also displayed in a popup on the
front-panel display.
Note that using this block too often in a trigger model could overflow the event log. It may also take
away from the time needed to process more critical trigger model blocks.
Example
TRIGger:BLOCk:LOG:EVENt 9, INFO2, "Trigger
model complete"
Set trigger model block 9 to log an event when
the trigger model completes.
Also see
None
:TRIGger:BLOCk:MEASure
This command defines a trigger block that makes a measurement.
Type Affected by Where saved Default value
Instrument reset
Usage
:TRIGger:BLOCk:MEASure <blockNumber>
:TRIGger:BLOCk:MEASure <blockNumber>, "<bufferName>"
:TRIGger:BLOCk:MEASure <blockNumber>, "<bufferName>", <count>
The sequence of the block in the trigger model
The name of the buffer, which must be an existing buffer; if no buffer is defined,
is used
Specifies the number of readings to make before moving to the next block in the
trigger model; set to a specific value or to infinite by setting to INF; to stop the
count, set to 0; if not specified, defaults to 1
Details
When trigger model execution reaches the block:
1. The instrument begins making a measurement.
2. The trigger model execution waits for the measurement to complete.
3. The instrument places the measurement into the specified reading buffer, which cannot be of the
writable buffer style.
