Model DMM7510

7½ Digit Graphical Sampling Multimeter Reference Manual Section 8:

TSP command reference

DMM7510-901-01 Rev. B / May 2015 8-123

Example

dmm.measure.func = dmm.FUNC_DC_VOLTAGE

dmm.measure.range = 10

dmm.measure.autozero.enable = dmm.OFF

dmm.measure.analogtrigger.mode = dmm.MODE_PULSE

dmm.measure.analogtrigger.pulse.level = 5

dmm.measure.analogtrigger.pulse.width = 30e-6

dmm.measure.analogtrigger.pulse.condition = dmm.CONDITION_LESS

dmm.measure.analogtrigger.pulse.polarity = dmm.POLARITY_BELOW

Set measure function to DC voltage.

Set range to 10 V.

Disable autozero.

Set the analog trigger mode to pulse.

Set the analog trigger level to 5 V.

Set the analog trigger pulse width to 30 µs.

Set the condition to be detect trigger within the pulse width.

Set the trigger to occur when the pulse is below the level.

Also see

Analog triggering overview (on page 3-64)

dmm.digitize.analogtrigger.pulse.condition (on page 8-76)

dmm.measure.analogtrigger.pulse.level (on page 8-124)

dmm.measure.analogtrigger.pulse.polarity (on page 8-125)

dmm.measure.analogtrigger.pulse.width (on page 8-126)
