Keithley DMM7510 Reference Manual

Model DMM7510
7½ Digit Graphical Sampling Multimeter Reference Manual Section 6:
SCPI command reference
DMM7510-901-01 Rev. B / May 2015 6-57
[:SENSe[1]]:<function>:ATRigger:EDGE:SLOPe
This command defines the slope of the analog trigger edge.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Measure configuration list
Save settings
Measure configuration list
RISing
Usage
[:SENSe[1]]:<function>:ATRigger:EDGE:SLOPe <setting>
[:SENSe[1]]:<function>:ATRigger:EDGE:SLOPe?
<function>
The function to which the setting applies; see Functions
<setting>
The direction:
• Rising: RISing
•
Falling: FALLing
Functions
VOLTage[:DC]
RESistance
TEMPerature
VOLTage[:DC]:RATio
VOLTage:AC
FRESistance
CONTinuity
DIGitize:VOLTage
CURRent[:DC]
DIODe
FREQuency[:VOLTage]
DIGitize:CURRent
CURRent:AC
CAPacitance
PERiod[:VOLTage]
Details
This is only available when the analog trigger mode is set to edge.
Rising causes an analog trigger event when the analog signal trends from below the analog signal
level to above the level.
Falling causes an analog trigger event when the signal trends from above to below the level.
Example
FUNC "CURR"
CURR:RANGE 3
CURR:AZER OFF
CURR:ATR:MODE EDGE
CURR:ATR:EDGE:LEV 2.5
CURR:ATR:EDGE:SLOP RIS
Set measure function to DC current.
Set range to 3 A.
Disable autozero.
Set the analog trigger mode to edge.
Set the analog trigger level to 2.5 A.
Set the analog trigger slope to rising.
Also see
[:SENSe[1]]:<function>:ATRigger:EDGE:LEVel (on page 6-56)
[:SENSe[1]]:<function>:ATRigger:MODE (on page 6-59)
Analog triggering overview (on page 3-64)

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
