Keithley DMM7510 Reference Manual

Model DMM7510
7½ Digit Graphical Sampling Multimeter Reference Manual Section 2:
General operation
DMM7510-901-01 Rev. B / May 2015 2-151
Save a user setup to internal memory
From the front panel:
1. Configure the Model DMM7510 to the settings that you want to save.
2. Press the MENU key.
3. Under Scripts, select Create Setup. The CREATE SETUP window is displayed.
4. Select Create. A keyboard is displayed.
5. Use the keyboard to enter the name of the script.
6. Select the OK button on the displayed keyboard. The script is added to internal memory.
Using SCPI commands:
Configure the instrument to the settings that you want to save. To save the setup, send the
command:
*SAV <n>
Where <n> is an integer from 0 to 4.
In the front-panel script menus, the setups saved with the *SAV command have the name Setup0x,
where x is the value you set for <n>.
Using TSP commands:
Configure the instrument to the settings that you want to save. To save the setup, send the
command:
createconfigscript("setupName")
Where setupName is the name of the setup script that will be created.
Save a user setup to a USB flash drive
From the front panel:
1. Save the user setup to internal memory, as described in Save a user setup to internal memory
(on page 2-151).
2. Insert the USB flash drive into the USB port on the front panel.
3. Press the MENU key.
4. Under Scripts, select Manage. The MANAGE SCRIPTS window is displayed.
5. In the Internal Scripts list, select the script you want to copy to the USB flash drive.
6. Select >. The file is transferred to the USB flash drive, and the corresponding filename is
displayed in the USB Scripts box.
Using TSP commands:
1. Save the user setup to internal memory, as described in Save a user setup to internal memory
(on page 2-151).
2. Insert the USB flash drive into the USB port on the front panel.
3. Send the command:
setupName.save("/usb1/USBSetupName")
Where setupName is the name of the user setup and USBSetupName is the name of the file on
the USB flash drive. You can use the same name for setupName and USBSetupName.
