6: SCPI command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter Refere
nce Manual
6-14 DMM7510-901-01 Rev. B / May 2015
*RCL
This command returns the instrument to the setup that was saved with the *SAV command.
Type Affected by Where saved Default value
Command only
Not applicable
Not applicable
Not applicable
Usage
*RCL <n>
<n>
An integer from 0 to 4 that represents the saved setup
Details
Restores the state of the instrument from a copy of user-saved settings that are stored in the setup
memory. The settings are saved using the *SAV command.
If you view the user-saved settings from the front panel of the instrument, these are stored as scripts
named Setup0<n>.
Example
*RCL 3
Restores the settings stored in memory location 3.
Also see
Saving setups (on page 2-150)
*SAV (on page 6-14)
*SAV
This command saves the present instrument settings as a user-saved setup.
Type Affected by Where saved Default value
Command only
Not applicable
Nonvolatile memory
Not applicable
Usage
*SAV <n>
<n>
An integer from 0 to 4
Details
Save the present instrument settings as a user-saved setup. You can restore the settings with the
*RCL command.
Any command that is affected by *RST can be saved with the *SAV command.
You can save up to 5 user-saved setups. Any settings that had been stored previously as <n> are
overwritten.
If you view the user-saved setups from the front panel of the instrument, they are stored as scripts
named Setup0<n>.

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
