Keithley DMM7510 Reference Manual

Section
8: TSP command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
Reference Manual
8-90 DMM7510-901-01 Rev. B / May 2015
dmm.digitize.func
This attribute determines which digitize function is active.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW) Yes
Restore configuration
Instrument reset
Power cycle
Measure configuration list
Nonvolatile memory dmm.FUNC_NONE
Usage
value = dmm.digitize.func
dmm.digitize.func = value
value
The digitize measurement function to make active:
• Current: dmm.FUNC_DIGITIZE_CURRENT
• Voltage: dmm.FUNC_DIGITIZE_VOLTAGE
• No digitize function selected (read only):
dmm.FUNC_NONE
Functions
dmm.FUNC_DC_VOLTAGE
dmm.FUNC_RESISTANCE
dmm.FUNC_ACV_FREQUENCY
dmm.FUNC_AC_VOLTAGE
dmm.FUNC_4W_RESISTANCE
dmm.FUNC_ACV_PERIOD
dmm.FUNC_DC_CURRENT
dmm.FUNC_DIODE
dmm.FUNC_DCV_RATIO
dmm.FUNC_AC_CURRENT
dmm.FUNC_CAPACITANCE
dmm.FUNC_DIGITIZE_CURRENT
dmm.FUNC_TEMPERATURE
dmm.FUNC_CONTINUITY
dmm.FUNC_DIGITIZE_VOLTAGE
Details
Set this command to the type of measurement you want to digitize.
Reading this command returns the digitize function that is presently active.
If a basic (non-digitize) measurement function is selected, this returns dmm.FUNC_NONE. The none
setting is automatically made if you select a function with dmm.measure.func or through the options
from the front-panel Measure Functions tab.
Example
dmm.digitize.func = dmm.FUNC_DIGITIZE_CURRENT
Set the measurement function to digitize
current.
Also see
Digitize functions (on page 2-127)
dmm.measure.func (on page 8-155)

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
