Recording a macro script
To record a macro script:
1. Press the MENU key.
2. Under Scripts, select Record.
3. Select the Start Macro button.
4. Make the settings that you want to record.
5. Press the MENU key.
6. Under Scripts, select Record.
7. Select the Stop Macro button. The Macro Script Name dialog box is displayed.
8. Enter a name for the script.
9. Select the OK button.
You can also stop or cancel recording from the Home screen. Select the Recording indicator in the
indicator bar.
After you create a macro script, you can use the other Scripts menu options to run and manage
scripts. Refer to Scripts menu (on page 2-47
) for information on the options.
Running a macro script
You can run a macro script from the front panel or from a remote interface.
To run a macro script from the front panel:
1. Press the MENU key.
2. Under Scripts, select Run.
3. Select the macro script to run.
4. Select Run Selected.
Using SCPI commands:
SCRipt:RUN "scriptName"
Where scriptName is the name of the macro script to run.
Using TSP commands:
scriptVar.run()
Where scriptVar is the name of the macro script to run.
