Keithley DMM7510 Reference Manual

Section
6: SCPI command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
Reference Manual
6-144 DMM7510-901-01 Rev. B / May 2015
:SYSTem:EVENtlog:SAVE
This command saves the event log to a file on a USB flash drive.
Type Affected by Where saved Default value
Command only
Not applicable
Not applicable
Not applicable
Usage
:SYSTem:EVENtlog:SAVE "<filename>"
:SYSTem:EVENtlog:SAVE "<filename>", <eventType>
<filename>
A string that holds the name of the file to be saved
<eventType>
Limits the event log entries that are saved to specific types; set to:
• ERRor: Saves only error entries
• WARNing: Saves only warning entries
• INFormational: Saves only informational entries
•
ALL: Saves all event log entries (default)
Details
This command saves all event log entries to a USB flash drive.
If you do not define an event type, the instrument saves all event log entries.
The extension .csv is automatically added to the file name.
Example
SYST:EVEN:SAVE "/usb1/July_error_log", ERR
Saves the error events in the event log to a
file on the USB flash drive named
July_error_log.csv.
Also see
:SYSTem:CLEar (on page 6-136)

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
