Keithley DMM7510 Reference Manual

Section
8: TSP command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
Reference Manual
8-62 DMM7510-901-01 Rev. B / May 2015
display.input.option()
This function allows you to create an option dialog box with customizable buttons on the front-panel display.
Type TSP-Link accessible
Affected by Where saved Default value
Function
Yes
Usage
display.BUTTON_OPTIONn = display.input.option(dialogTitle, buttonTitle1,
buttonTitle2)
display.BUTTON_OPTIONn = display.input.option(dialogTitle, buttonTitle1,
buttonTitle2, buttonTitleN, ... buttonTitleN)
n
The number of the button that is selected from the front-panel display; nil if Cancel
is pressed on the keypad; buttons are numbered top to bottom, left to right
dialogTitle
A string that contains the text to be displayed as the title of the dialog box on the
front-panel display; up to 32 characters
buttonTitle1
A string that contains the name of the first button; up to 15 characters
buttonTitle2
A string that contains the name of the second button; up to 15 characters
buttonTitleN
A string that contains the names of subsequent buttons, where N
is a number from 3
to 10; you can define up to 10 buttons; each button can be up to 15 characters
Details
Buttons are created from top to bottom, left to right. If you have more than five buttons, they are
placed into two columns.
The prompt is displayed until it has been responded to. You can only send one input prompt
command at a time.

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
