[:SENSe[1]]:<function>:DETector:BANDwidth
This command selects the detector bandwidth for AC current and AC voltage measurements.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Measure configuration list
Save settings
Measure configuration list
30
Usage
[:SENSe[1]]:<function>:DETector:BANDwidth <n>
[:SENSe[1]]:<function>:DETector:BANDwidth DEFault
[:SENSe[1]]:<function>:DETector:BANDwidth MINimum
[:SENSe[1]]:<function>:DETector:BANDwidth MAXimum
[:SENSe[1]]:<function>:DETector:BANDwidth?
[:SENSe[1]]:<function>:DETector:BANDwidth? DEFault
[:SENSe[1]]:<function>:DETector:BANDwidth? MINimum
[:SENSe[1]]:<function>:DETector:BANDwidth? MAXimum
<function>
The function to which the setting applies; see Functions
<n>
3 Hz, 30 Hz, or 300 Hz
Functions
VOLTage[:DC]
RESistance
TEMPerature
VOLTage[:DC]:RATio
VOLTage:AC
FRESistance
CONTinuity
DIGitize:VOLTage
CURRent[:DC]
DIODe
FREQuency[:VOLTage]
DIGitize:CURRent
CURRent:AC
CAPacitance
PERiod[:VOLTage]
Details
You can set the detector bandwidth to improve measurement accuracy. Select the bandwidth that
contains the lowest frequency component of the input signal. For example, if the lowest frequency
component of your input signal is 40 Hz, use a bandwidth setting of 30 Hz.
If the bandwidth is set to 3 Hz or 30 Hz, the autozero feature is always enabled and the integration
rate is fixed.
Example
FUNC "VOLT:AC"
VOLT:AC:DET:BAND 30
Set the measure function to AC volts.
Set the detector bandwidth for AC volts to 30 Hz.
Also see
[:SENSe[1]]:<function>:APERture (on page 6-53)
[:SENSe[1]]:<function>:AZERo[:STATe] (on page 6-72)
[:SENSe[1]]:<function>:NPLCycles (on page 6-85)
[:SENSe[1]]:AZERo:ONCE (on page 6-114)
