Keithley DMM7510 Reference Manual

Section
6: SCPI command reference Model DMM7510 7½ Digit Graphical Sampling Multimeter
Reference Manual
6-38 DMM7510-901-01 Rev. B / May 2015
DIGital subsystem
The commands in the DIGital subsystem control the digital I/O lines.
:DIGital:LINE<n>:MODE
This command sets the mode of the digital I/O line to be a digital line, trigger line, or synchronous line and sets
the line to be input, output, or open-drain.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Save settings
DIG, IN
Usage
:DIGital:LINE<n>:MODE <lineType>, <lineDirection>
:DIGital:LINE<n>:MODE?
<n>
The digital I/O line (1 to 6)
<lineType>
Sets the digital line control type; the options are:
• Allow direct digital control of the line: DIGital
• Configure for trigger control: TRIGger
• Configure as a synchronous master or acceptor:
SYNChronous
<lineDirection>
Sets the line direction; the options are:
• Input: IN
• Output: OUT
• Open drain: OPENdrain
• Master: MASTer
• Acceptor: ACCeptor
See Details for valid combinations with line type.
Details
You can specify the line type and line direction parameters to configure each digital I/O line into one
of the following modes:
• Digital open-drain, output, or input
• Trigger open-drain, output, or input
• Trigger synchronous master or acceptor
A digital line allows direct control of the digital I/O lines by writing a bit pattern to the lines. A trigger
line uses the digital I/O lines to detect triggers.

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
