Keithley DMM7510 Reference Manual

Model DMM7510
7½ Digit Graphical Sampling Multimeter Reference Manual Section 6:
SCPI command reference
DMM7510-901-01 Rev. B / May 2015 6-137
:SYSTem:COMMunication:LAN:CONFigure
This command specifies the LAN configuration for the instrument.
Type Affected by Where saved Default value
Command and query Rear panel LAN reset Nonvolatile memory AUTO
Usage
:SYSTem:COMMunication:LAN:CONFigure "AUTO"
:SYSTem:COMMunication:LAN:CONFigure "MANual,<IPaddress>"
:SYSTem:COMMunication:LAN:CONFigure "MANual,<IPaddress>,<NETmask>"
:SYSTem:COMMunication:LAN:CONFigure "MANual,<IPaddress>,<NETmask>,<GATeway>"
:SYSTem:COMMunication:LAN:CONFigure?
AUTO
Use automatically configured LAN settings (default)
MANual
Use manually configured LAN settings
<IPaddress>
LAN IP address; must be a string specifying the IP address in dotted decimal notation;
required if the mode is set to manual (default "0.0.0.0")
<NETmask>
The LAN subnet mask; must be a string in dotted decimal notation (default
"255.255.255.0")
<GATeway>
The LAN default gateway; must be a string in dotted decimal notation (default "0.0.0.0")
Details
This command specifies how the LAN IP address and other LAN settings are assigned. If automatic
configuration is selected, the instrument automatically determines the LAN information. When method
is automatic, the instrument first attempts to configure the LAN settings using dynamic host
configuration protocol (DHCP). If DHCP fails, it tries dynamic link local addressing (DLLA). If DLLA
fails, an error occurs.
If manual is selected, you must define the IP address. You can also assign a subnet mask, and
default gateway. The IP address, subnet mask, and default gateway must be formatted in four groups
of numbers, each separated by a decimal. If you do not specify a subnet mask or default gateway, the
previous settings are used. When specifying multiple parameters, do not use spaces after the
commas.
The query form of the command returns the present settings in the order shown here.
Automatic:
AUTO,<IPaddress>,<NETmask>,<GATeway>
Manual:
MANual,<IPaddress>,<NETmask>,<GATeway>
Example
SYST:COMM:LAN:CONF "MANUAL,192.168.0.1,255.255.240.0,192.168.0.3"
SYST:COMM:LAN:CONF?
Set the IP address to be set manually, with the IP address set to 192.168.0.1, the subnet mask to
255.255.240.0, and the gateway address to 192.168.0.3.
Query to verify the settings. The response to the query should be:
manual,192.168.0.1,255.255.240.0,192.168.0.3
Also see
:SYSTem:COMMunication:LAN:MACaddress? (on page 6-138)
