dmm.trigger.digitize.stimulus
This attribute sets the instrument to digitize a measurement the next time it detects the specified trigger event.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW) Yes
Restore configuration
Instrument reset
Power cycle
Configuration script dmm.EVENT_NONE
Usage
event = dmm.trigger.digitize.stimulus
dmm.trigger.digitize.stimulus = event
event
The event to use as a stimulus; see Details
Details
This command is intended to provide the lowest possible latency between a trigger event such as
digital I/O and a reading. It forces the instrument to make a digitize measurement the next time it
detects the specified trigger event. Options for the trigger event parameter are in the following table.
A digitize function must be active before sending this command. The measurement is digitized for the
active function. If a measure function is active, an error is generated.
Before using this command, set the active reading buffer. Readings are stored in the active buffer.
If the count is set to more than 1, the first reading is initialized by this trigger. Subsequent readings
occur as rapidly as the instrument can make them. If a trigger occurs during the group measurement,
the trigger is latched and another group of measurements with the same count will be triggered after
the current group completes.
If the stimulus is set to none, this command has no effect on readings.
Trigger events
Event description Event constant
No trigger event
trigger.EVENT_NONE
Front-panel TRIGGER key press
trigger.EVENT_DISPLAY
Notify trigger block N (1 to 8) generates a trigger event when
the trigger model executes it
trigger.EVENT_NOTIFYN
A command interface trigger (bus trigger):
• Any remote interface: *TRG
• GPIB only: GET bus command
•
VXI-11: VXI-11 command device_trigger
trigger.EVENT_COMMAND
Line edge (either rising, falling, or either based on the
configuration of the line) detected on digital input line N
(1 to 6)
trigger.EVENT_DIGION
Line edge detected on TSP-Link synchronization line N
(1 to 3)
trigger.EVENT_TSPLINKN
Appropriate LXI trigger packet is received on LAN trigger
object N (1 to 8)
trigger.EVENT_LANN
Trigger event blender N (1 to 2), which combines trigger
events
trigger.EVENT_BLENDERN
Trigger timer N (1 to 4) expired
trigger.EVENT_TIMERN
Analog trigger
trigger.EVENT_ANALOGTRIGGER
External in trigger
trigger.EVENT_EXTERNAL
