2: General operation Model DMM7510 7½ Digit Graphical Sampling Multimeter
2-22 DMM7510-901-01 Rev. B / May 2015
The secondary measurement window has the following control options:
Button Description
Secondary Measure
Enables or disables the secondary measurement feature. The
primary measurement is not affected by the state of the secondary
Second Function
Displays the list of functions so you can select the measure
function for the secondary measurement.
Swap Primary
Switches the primary and secondary functions.
Depending on the selected functions, a relay may click when the instrument switches between the
measurement types. Leaving secondary measurements on for extended periods may shorten the life
of the relays.
Menu overview
To access the main menu, press the MENU key on the Model DMM7510 front panel. The figure
below shows the organization of the main menu.
Figure 21: Model DMM7510 main menu
The main menu includes submenus that are labeled in green across the top of the display. Touching
an icon in a submenu opens an interactive screen.
