7½ Digit Graphical Sampling Multimeter Reference Manual Section 2:
DMM7510-901-01 Rev. B / May 2015 2-23
Measure menu
The Measure menus allow you to select, configure, and perform measure operations from the front
panel. The following topics describe the settings that are available on these interactive screens.
QuickSet menu
The QuickSet icon at the top left of the main menu allows you to change
the function, adjust performance, and set quick-setup options. You can
also access the QuickSet menu by pressing the QUICKSET key on the
front panel.
Setting Description
Function
Selects the measure function that the instrument uses. Refer to
DMM measurement overview (on page 2-94).
Performance
Adjusts the balance between resolution and speed of the
instrument. Refer to Using the Performance slider (on page 2-135).
Quick Setups
Sets up specific measure tests by following a few prompts. Refer to
Using Quick Setups (on page 2-135).
Measure Settings menu
The Measure Settings menu contains settings for the presently selected measure
function, which is identified by the function indicator in the upper right corner of the
menu. The available settings depend on the front-panel FUNCTION key selection.
Function indicators
The Function indicator in the upper right corner of some menu screens displays which function the
instrument is using to make measurements. The indicators include DCV Ratio to indicate that the DC
voltage ratio function is selected and 2W Res to indicate that the 2-wire resistance function is
selected. You can select the indicator to open the list of functions and change the active function.
